- LCD panel displays group, channel, error code, and battery fuel gauge simultaneously.
- Compact, lightweight and streamline shape for easy wearing.
- Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
- Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
- Belt clip allows 360 degrees rotating to suit transmitter wearing.
- World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
- Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
- Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
- Professional quality ensures no impact-damage.
| Housing Material |
Plastic |
| Oscillation Mode |
PLL Synthesized |
| Frequency Range |
UHF 620~950MHz |
| Bandwidth |
24MHz |
| Channel Set-Up |
ACT Sync |
| RF Output Power |
10~30mW (country dependent) |
| Spurious Emission |
<-55dBc |
| Max. Input Level |
0dBV |
| Battery |
2 AA alkaline or rechargeable batteries |
| Dimensions |
63(W)×105(H)x21(D)mm / 2.5(W)x4.1(H)x0.8(D)" |
| Weight |
Weight 95g / 3.4oz (excluding batteries) |
| Patents & Approvals |
Patented. Telecom and safety regulations approved. |
| Notes |
Refer to actual product in the event of product discrepancy.
Frequency range and maximum deviation comply with the regulations of different countries. |
| |
| |
|
|
|
|
 |
 |
 |
 |
 |
